Ultrasonic Six Parameter Meteorological Station (304SS)

KH.CQX-6 All-in-One Ultrasonic Weather Sensor | Wind, Temperature, Humidity, Pressure & Rainfall Monitoring (304 Stainless Steel Housing Version)

Product Introduction

The KH.CQX-6 Ultrasonic Weather Sensor is a fully integrated six-parameter meteorological instrument designed for precise and continuous outdoor monitoring. It uses advanced frequency-converting ultrasonic technology to measure wind speed and direction, eliminating errors caused by timer drift and temperature variation. The 304 stainless steel version retains all core functions while upgrading the housing and rainfall measurement method. It integrates wind, temperature, humidity, pressure, and piezoelectric rainfall monitoring, transmitting real-time environmental data through digital interfaces.

Key Features

• Hidden ultrasonic probe design: Top-cover structure protects the probe from rain, snow, and crosswind interference.
• Six-in-one compact integration: Wind speed, wind direction, temperature, humidity, pressure, and piezoelectric rainfall combined in one device.
• High-precision ultrasonic wind measurement: Frequency conversion ensures stable, accurate performance without threshold limitations.
• Strong anti-interference: Built-in watchdog and automatic reset system ensure uninterrupted long-term operation.
• Maintenance-free operation structure: No moving parts or on-site calibration required.
• 304 stainless steel housing: Provides exceptional corrosion resistance, UV protection, salt-spray resistance, and mechanical strength, ideal for coastal regions, high-humidity areas, industrial environments, and long-term outdoor exposure.
• Flexible communication options: Standard RS485 MODBUS RTU; optional RS232, USB, or Ethernet.
• Wireless transmission optional: Supports remote monitoring with a minimum update interval of one minute.
• Easy installation: Snap-on structure ensures secure assembly during transportation and field mounting.

Application Scenarios

• Automatic weather stations
• Smart agriculture and irrigation systems
• Urban environmental and climate monitoring
• Wind and solar energy assessment
• Marine and offshore monitoring
• Airport and aviation meteorology
• Highways, bridges, and tunnel safety
• Smart city and IoT weather networks

Technical Specifications

Parameter	Range	Accuracy	Resolution
Wind Speed	0–60 m/s	±0.1 m/s	0.01 m/s
Wind Direction	0–360°	±2°	1°
Air Temperature	-40–80°C	±0.3°C	0.01°C
Relative Humidity	0–100% RH	±3% RH	0.01% RH
Atmospheric Pressure	300–1100 hPa	±0.25%	0.1 hPa
Optical Rainfall	0–4 mm/min	≤±4%	—
